1、 键：启动键，开机状态按下此键，控制器关机，关机状态按下此键，控制器开机，同时点亮启动按键指示灯，初始状态：无风机输出，定时关20分钟，关机状态下仅显示水温区域，液晶背光关闭；开机状态下“ ”上下两行轮流点亮显示，动态显示，风机开启后 动态显示，液晶背光常开；
2、“O3”键：蓝氧建，在风机开启状态下按下此键，蓝氧的开启或关闭，蓝氧指示灯 对应于臭氧的工作状态；
3、“ ”键：开机状态按下此键，调整定时时间，初始为定时关20分钟，每按一次定时，定时时间按照每5分钟递增循环，最大为30分钟，最小为10分钟，开机后，控制器始终运行于定时关状态下，定时键指示灯在按下时点亮；
4、显示面板“ ”、“ ”：向上及向下键，实现风速的增加或者减小，档位显示于能量区域，风速档位一共6档，在温度设定时，同时可设定辅热温度调整键；
5、“ ”键:辅热键，辅热初始温度为42℃，长按辅热键3秒进入温度设定，温度设定范围39~44℃，设定状态下温度显示区域闪烁，此时可通过增强键或减弱键进行温度调整，辅热开启时，“ ”指示灯点亮；
6、液晶显示面板“ ”符号：当负离子开启时，符号点亮，关闭时，符号熄灭；
1. Key: start key, press this key in the startup state, the controller will shut down, press this key in the shutdown state, the controller will start up, and the start key indicator will be lit at the same time. The initial state: no fan output, turn off regularly for 20 minutes, only the water temperature area will be displayed in the shutdown state, and the LCD backlight will be turned off; In the power on state, the upper and lower lines of "" are lit in turn for dynamic display. After the fan is turned on, it is displayed dynamically, and the LCD backlight is normally on;
2. "O3" key: Blue oxygen construction. Press this key when the fan is on, the blue oxygen will be on or off, and the blue oxygen indicator light corresponds to the working state of ozone;
3. "" key: press this key in the power on state to adjust the timing time. The initial timing is off for 20 minutes. Each time you press it, the timing time will increase and cycle every 5 minutes, with a maximum of 30 minutes and a minimum of 10 minutes. After power on, the controller will always operate in the timing off state, and the timing key indicator will be on when pressed;
4. Display panel "", "": up and down keys to increase or decrease the wind speed. The gear is displayed in the energy area. The wind speed gear has 6 gears in total. When setting the temperature, the auxiliary heat temperature adjustment key can be set at the same time;
5. "" key: auxiliary heating key. The initial temperature of auxiliary heating is 42 ℃. Press and hold the auxiliary heating key for 3 seconds to enter the temperature setting. The temperature setting range is 39 ~ 44 ℃. Under the setting state, the temperature display area flashes. At this time, the temperature can be adjusted through the increase key or decrease key. When the auxiliary heating is turned on, the "" indicator light is on;
6. "Symbol" of LCD panel: when the anion is turned on, the symbol is on, and when it is turned off, the symbol is off;
